Ultra-Case Powerglide Transmissions: Quite possibly the BEST powerglide transmission you can get your hands on! With multiple combinations available we can build you a transmission that can handle any amount of power up to 3000hp! These transmissions utilize the latest in technology and quality materials. All Ultra-Case Transmissions come SFI 4.1 certified so no additional shields are needed. Couple these transmissions with your choice of an Ultra-Bell SFI 30.1 bellhousing that will allow you to mount these great Powerglides behind Chevrolet, Ford, and Mopar applications (Ultra-Bell Sold Separately). Basic Features Include: Turbo Spline Input Shaft, Deep Pan, Forward Pattern Pro-Tree Transbrake, Universal Shifter Arm, Billet High Gear Hub, Race Modified Front Pump, Fully Dyna Tested, and ready for Ultra-Bell Installation.

Description

  • 1500hp rated in most applications
  • Forward Pattern Pro-Tree Transbrake Valvebody
  • SFI Certified Ultra-Case Transmission Housing
  • 1.80 Straight Cut Gearset with 4340 Chromoly Output Shaft – Standard Length
  • Billet Dual O-Ring Servo Piston
  • Billet Servo Cover
  • Roller Thurst Between Pump and Drum
  • Performance Clutches and Steels
  • Kevlar Low Gear Band
  • Hardened (Grade 8) Band Adjuster
  • 300M Turbo Spline Input Shaft
  • 300M Stator Support Shaft
  • Cast Aluminum Deep Pan
  • Billet Aluminum Roller Rear Support
  • Prepped for Ultra-Bell (Ultra-Bell sold separate)
  • Roller Bearing Long Length Tailhousing (recommend using a hardened yoke)
  • Universal Shifter Arm – Can Be Installed in Up or Down Position
  • No speedometer provision
  • Vent is tapped for 1/8” NPT
  • Fully Dyno Tested
