Description:

• HP & Torque: 341 HP / 371 FT LBS
• Compression Ratio: 9:1
• Aluminum Heads
• Hydraulic Roller Cam
• Steel Crankshaft
• Hypereutectic Pistons

Block:

• NEW BluePrint Cast Iron Block
• Manufactured and Machined in the USA!
• 4-Bolt Main
• 4.000" Bore
• 1-Piece Rear Main Seal
• Mech fuel pump provision: Yes
• Passenger Side Dipstick
• Drilled and tapped for clutch linkage

Rotating Assembly:

• Steel Crankshaft
• 3.480" Stroke
• Forged 5.700" connecting rods
• Hypereutectic pistons
• Internal Front/ External Rear engine balance

Cylinder Heads:

• BluePrint Aluminum Cylinder Heads - H8002K
• 64cc chamber
• 2.02" intake/1.60" exhaust valves
• 195cc intake/75cc exhaust runners

Cam Specs:

• Cam Type: Roller
• .477 Intake .471 Exhaust
• 202 Intake / 212 Exhaust duration
• @ .050 - 115-degree lobe separation

Ignition Timing:

• 32 Degrees Total at 3500 RPM

Also Includes:

• Valve covers
• Oil pan
• Timing cover
• Aluminum intake

• HEI distributor

• EFI system

Notes:

• This engine is an excellent cruiser and daily driver engine.  This engine makes up to 18 inches of vacuum, and is designed to work excellent with power brakes, stock torque converter, stock gearing, and run on 87 octane fuel
• The performance aluminum cylinder heads on this engine feature a .500 raised port vs OEM.
